400G-OSFP56

•

  400G-LR4 OSFP56

  400G-LR4 OSFP56 based on 8 channels of 50G-PAM4 electrical and 4 channels of 100G-PAM4 optical parallel lanes, duplex LC connector, 10km maximum reach via single mode fiber, case temperature range of 0℃-70℃, comply with IEE802.3bs and OSFP MSA, and support CMIS.

  Applications

  · Ethernet
  · InfiniBand
•

  400G-FR4 OSFP56

  400G-FR4 OSFP56 based on 8 channels of 50G-PAM4 electrical and 4 channels of 100G-PAM4 optical parallel lanes, duplex LC connector, 2km maximum reach via single mode fiber, case temperature range of 0℃-70℃, comply with IEE802.3bs and OSFP MSA, and support CMIS.

  Applications

  · Ethernet
  · InfiniBand
•

  400G-DR4 OSFP56

  400G-DR4 OSFP56 based on EML, 8 channels of 50G-PAM4 electrical and 4 channels of 100G-PAM4 optical parallel lanes, single optical port of MPO12, 500m maximum reach via single mode fiber, case temperature range of 0℃-70℃, comply with IEE802.3bs and OSFP MSA, and support CMIS.

  Applications

  · Ethernet
  · InfiniBand
•

  400G-SR8 OSFP56

  400G-SR8 OSFP56 based on VCSEL, 8 channels of 50G-PAM4 electrical and optical parallel lanes, single optical port of MPO-16, up to 70m reach via OM3 multimode fiber and 100m reach via OM4 multimode fiber, case temperature range of 0℃-70℃, comply with IEEE 802.3bs and OSFP MSA.

  Applications

  · Ethernet
  · InfiniBand
•

  400G-AOC OSFP56

  400G-AOC OSFP56 Series is based on VCSELs. These products feature eight channels of 50G PAM4 electrical signals and eight channels of 50G PAM4 optical signals, with a transmission distance of up to 100m over OM3 MMF. They have a case temperature range of 0℃-70℃ and comply with IEEE 802.3bs and OSFP MSA.

  Applications

  · Ethernet
  · InfiniBand
